2.3.2 Overdrachtsprotocollen

Subnetten in klasse B

Bits	Subnetmasker	Subnetten	Host/subnet	Totaal hosts	CIDR
1	255.255.128.0	2	32766	65532	/17
2	255.255.192.0	4	16382	65528	/18
3	255.255.224.0	8	8190	65520	/19
4	255.255.240.0	16	4094	65504	/20
5	255.255.248.0	32	2046	65472	/21
6	255.255.252.0	64	1022	65408	/22
7	255.255.254.0	128	510	65280	/23
8	255.255.255.0	256	254	65024	/24
9	255.255.255.128	512	126	64512	/25
10	255.255.255.192	1024	62	63488	/26
11	255.255.255.224	2048	30	61440	/27
12	255.255.255.240	4096	14	57344	/28
13	255.255.255.248	8192	6	49152	/29
14	255.255.255.252	16384	2	32768	/30

Subnetten in klasse A

Bits	Subnetmasker	Subnetten	Host/subnet	Totaal hosts	CIDR
1	255.128.0.0	2	8388606	16777212	/9
2	255.192.0.0	4	4194302	16777208	/10
3	255.224.0.0	8	2097150	16777200	/11
4	255.240.0.0	16	1048574	16777184	/12
5	255.248.0.0	32	524286	16777152	/13
6	255.252.0.0	64	262142	16777088	/14
7	255.254.0.0	128	131070	16776960	/15
8	255.255.0.02	256	65534	16776704	/16
9	255.255.128.0	512	32766	16776192	/17
10	255.255.192.0	1024	16382	16775168	/18
11	255.255.224.0	2048	8190	16773120	/19
12	255.255.240.0	4096	4094	16769024	/20
13	255.255.248.0	8192	2046	16760832	/21
14	255.255.252.0	16384	1022	16744448	/22
15	255.255.254.0	32768	510	16711680	/23
16	255.255.255.0	65536	254	16646144	/24
17	255.255.255.128	131072	126	16515072	/25
18	255.255.255.192	262144	62	16252928	/26
19	255.255.255.224	524288	30	15728640	/27
20	255.255.255.240	1048576	14	14680064	/28
21	255.255.255.248	2097152	6	12582912	/29
22	255.255.255.252	4194304	2	8388608	/30
